CAT6 ÇIKIŞLI TAŞINABİLİR EU BAND WİFİ 6 DESTEKLİ 3000MAH PİLLİ 4G+ MODEM

Design
Weight Depend on the goods 45G±2
Type CAT 4 4G Mifi 4G LTE
LED LED ONLY yes
User Manual Support yes
Power supply USB 5V-1A
Chipset Wireless communication chipset QUALCOMM
WiFi chipset QUALCOMM
Baseband CPU model MDM8916
WiFi /Bluetooth model WCN3620/WCN3660
SIM slot SIM MINI
Device memory Flash/RAM: 32G+4G
USB interface USB-A 2.0
Max. WIFI Users 8 users 2.4GHz
Indicator LED 4G+WIFI
Radio frequency Radio frequency chip RTR4905
Main antenna FPC
WIFI antenna 2.4G onboard antenna
LTE band Band 1 .3.5.7.8.20.38.39.40.41. Frequency band can be customized
WCDMA band Band 1.5.8
Wireless MIMO technology N/A Single antenna transmit and receive
Wireless transmit power "TDD-LTE:21dbm±2dbm
FDD-LTE:21dbm±2dbm
WCDMA :21dbm±2dbm"
WIFI band Support 2.4GHz
WIFI MIMO technology Support 802.11b/g/n 1*1
Rate and standard LTE TDD-LTE:Cat4 130 Mbps DL / 35Mbps UL FDD-LTE Cat4 150 Mbps DL / 50Mbps UL Theoretical peaks, related to test environment, bandwidth, and channel settings
WCDMA "DL 21Mbp
UL 5.76Mbps"
3GPP/3GPP2 protocol LTE FDD/TDD Rel 9 YES
WiFi standard 802.11 b/g/n(1*1 only) YES
WiFi Authentication WPA-PSK/WPA2-PSK default The default authentication method can be customized
Reset button Yes YES
Working environment Operating temperature -10~ 60° C YES
Storage temperature -45 ~ 85° C YES
Humidity 10%~ 95% YES
