SECURITECH 5KM GIGABIT 24V POE AP-REPEATER-CLIENT 2 Lİ SET

5.8G 5KM 900M Wireless CPE for CCTV

500mW High power output, coverage up to 5KM
for PTP and PTMP application

Wireless AC speed up to 900Mbps Bipolar 16dBi antenna 2 *1000M
Bipolar 16dBi antenna 2 *1000

5KM wireless transmit for Carry 200pcs camera Max

4920-6100MHz Extension Channel
10KV Lightning Protection

Product Specifications
Product name 900MHigh-power dual gigabit digital wireless bridge
Product Model SCT-BH5
Hardware Specifications
Hardware system
Memory 128MB
FLASH 8MB
PA High Power PAs
Wireless parameters Protocol standards Support IEEE while being backward compatible with IEEE /an802.11ac802.11a
Operating frequency band 5.8GHz: 5180MHz to 5825MHz
Wireless rate 866Mbps
Transmit power 25dBm ± 2 dBm
Reception sensitivity -92dBm ± 2 dBms
Physical interface Network interface 2 10/100/1000Mbps Ethernet ports (both support 24V PoE power supply)
Hardware buttons 1 digital button /RESET button
Power port 1 DC power port, supporting 12V DC power supply
Pull the switch 1 pull switch (A end, B end free switching)
Digital display 1 digital display (support 0~9~A~F 16 channel display)
Wireless type Wireless type Built-in 14dBi dual-polarized directional antenna5.8G
Indicator light LED indicator SYS, LAN1, LAN2, WLAN, LINK, in that order
Power Supply/Power consumption Mode of power supply Support DC12V power supply and 24V PoE power supply1A
Overall power < 10 w.
Product accessories Mainframe 900MHigh-power dual gigabit digital wireless bridge s*1
Power adapter 24V Gigabit PoE power supply0.5A
Other User Manual *1, Warranty card *1, Certificate *1, stainless steel hoop *1
Appearance/Packaging Exterior color white.
Product size 250mm** (L*W*H)90mm54m
Package size 295mm** (L*W*H) (in a pair)283mm82m
Weight 2kg< (in a pair)
Other Optimal power distance for PoE cables 65?Within (Category 5 network cable or above)
Bridging distance 0-5 km
IPC with machine capacity 20 way, no stuck, no delay
Installation method Pole installation, wall mounted installation, bracket installation
Level of protection IP65, 2KV lightning protection
Software Specifications
Bridge networking mode Digital pairing Supported, digital display, one-click pairing, convenient/easy/quick
Manual pairing Support (enabled when digital display function is turned off)
Point-to-point bridge support
Point-to-multipoint bridging Support
Networking Work mode AP mode, WDS bridge mode, WDS repeater mode, AP-client mode, AP-client +AP mode
LAN Settings Support
WAN/LAN port traffic control Support
DHCP Server Support
Network traffic monitoring Support
Wireless Settings Wireless switch support
Wireless timed enable Support
SSID Settings Support
SSID Hiding Support
Wireless Security Supports multiple encryption methods
Wireless mode Settings Support
Bandwidth Settings Support
Wireless channel setup Supported, spread spectrum available
Wireless subscriber isolation support
Wireless power regulation Support
Guest network Settings Support
Access Control Support
Systems administration Web interface Management Support
User Management Support
Firmware upgrades Support







Interface description

Product dimensions

Product application
Wireless monitoring transmission point-to-point application 1






Two, wireless monitoring transmission point-to-point application 2






Third, wireless monitoring transmission point-to-multipoint application 3







Fourth, Internet of Things data transmission application






5. Internet wireless transmission application 1



6. Internet wireless transmission Application 2




7. Internet coverage Application 3
